Nade Gas Generation Equipment Nitrogen Evaporator MD200-1 5~150C

Nade Gas Generation Equipment Nitrogen Evaporator MD200-1   Product Description MD200-1 Sample Concentration consists of a base and stand assembly, sample holder and gas distribution system. Test tubes are held in a bolck .   Feature 1. High precision and wide range of temperature control 2. Blowing a large number of samples at one time 3. Blowing each sample independently 4. Amount of airflow can be adjusted 5. Easy operation; safe and reliable to use     Specification 1.Temperature range: RT. 5~150°C 2.Temperature control discrepancy:  ≤ ±0.5°C (RT 5°C~150°C) ≤ ±1°C (100°C ~ 150°C) 3. Low Nitrogen consumption of 330ml/min/sample 4. Time required for temperature to increase from 40°C to 150°C: ≤30m minutes 5 .Maximum input power: 200W 6. Temp. control discrepancy: ± 0.1°C 7. Dimensions: 280W x240D x 500H 8. Net weight: 6Kg 9. All units will fit and are recommended to be used in a bench-top.ventiated hood 10. Needles length: 150mm 11. Standard Blocks: See “Blocks for MD200   Blocks for MD200 Type   Parameter   Capacity   Dimension (mm)   BK01 6 mm 49 96 x 96 x 49 BK02 7 mm 49 96 x 96 x 49 BK03 10 mm 25 96 x 96 x 49 BK04 12 mm 25 96 x 96 x 49 BK05 13 mm 25 96 x 96 x 49 BK06 15 mm 12 96 x 96 x 49 BK07 15 mm 16 96 x 96 x 49 BK08 16 mm 12 96 x 96 x 49 BK09 16 mm 16 96 x 96 x 49 BK10 19 mm 12 96 x 96 x 49 BK11 19 mm 16 96 x 96 x 49 BK12 20 mm 9 96 x 96 x 49 BK13 26 mm 9 96 x 96 x 49 BK14 28 mm 4 96 x 96 x 49 BK15 40 mm 4 96 x 96 x 49 BK16 0.5 ml Centrifuge tube 49 96 x 96 x 49 BK17 1.5 ml Centrifuge tube 25 96 x 96 x 49 BK18 2.0 ml Centrifuge tube 25 96 x 96 x 49
