MEMS Base Pressure Sensor
14 sold in last 1 hour
Hurry! Over 17 people have this in their carts
Estimated Delivery: Thu, Jul 02 – Fri, Jul 03 (Excl Sun)
... people are viewing this right now
Products Description PE351 utilizes MEMS technology for its metal-based pressure-sensitive chip, with strain resistance applied directly on a 17-4 PH stainless steel substrate. The substrate undergoes elastic deformation, producing a linearly related mV voltage signal indicative of the measured pressure. Tailored for OEM manufacturers and integrators with stringent sensor standards, it offers high reliability and stability. The chip outputs an mV voltage signal, allowing customers to process it as per their specific requirements, ensuring flexibility in applications. Product Features MEMS and sputtered film technology ensures exceptional long-term stability and high reliability Wide working temperature range, low temperature drift, and superior overload capacity Integrated structure, adaptable for various fluid media Constructed with 17-4PH stainless steel material, providing robust corrosion resistance Compact size for installation in confined spaces Product Specification Measuring range(MPa) 0.5MPa~250MPa Measuring medium Gases, liquids compatible with stainless steel Pressure type Gauge pressure, absolute pressure Accuracy ±0.03%F.S, ±0.05%F.S, ±0.1%F.S, ±0.2%F.S, ±0.5%F.S, ±1%F.S Working temp. -40~ 105℃ or by customized Long-term stability ±0.2%F.S/year Burst pressure 1000%~4000%F.S (the max is ≤400MPa) Allowable overload 150%~200%F.S or by customized Response time ≤0.1ms Material 17-4PH Product Dimensions
