DULUX LED D10 EM & AC MAINS V 5W 840 G24D-1

PRODUCT DESCRIPTION Product benefits Easy installation Low energy consumption Easy relamping thanks to compact design Operation directly on 230 V AC mains possible Areas of application General illumination within ambient temperatures from -20… 45 °C Supermarkets and department stores Walkways and corridors Hotels, restaurants Product features LED replacement for conventional compact fluorescent lamps for use in CCG luminaires or on AC mains Lifetime up to 30,000 h Rotatable base around its longitudinal axis (± 90°) Single-ended two-pin plug-in G24d base Type of protection: IP20 Mercury-free lamps Safety advice Not suitable for tandem operation. The operating temperature range of DULUX LED is restricted. In case of doubt regarding suitability of the application please measure Tc temperature on the product prior to installation. All electrical connections must be made by a qualified person. Do not touch the lamp with bare fingers. Must not be used if outer bulb is defective. Lamp not suitable for emergency operation. Electrical data Nominal wattage 5 W Construction wattage 5.00 W Nominal voltage 220…240 V Operating mode CCG, AC Mains Nominal current 23 mA Type of current AC Inrush current 13.7 A Suitable for DC input Yes Input voltage DC 186…260 V 1) Operating frequency 50/60 Hz Mains frequency 50/60 Hz Max. lamp number on MCB B10 A 43 Max. lamp number on MCB B10 A – CCG without compensation 174 Max. lamp number on MCB B10 A – CCG with compensation 14 Max. lamp number on MCB B16 A 54 Max. lamp number on MCB B16 A – CCG without compensation 273 Max. lamp number on MCB B16 A – CCG with compensation 17 Total harmonic distortion ≤ 30 % 1) Permitted voltage range Photometrical data Luminous flux 600 lm Luminous efficacy 120 lm/W Light color (designation) Cool White Color temperature 4000 K Color rendering index Ra 80 Light color 840 Rated LLMF at 6,000 h 0.90 Flickering metric (Pst LM) 1.0 Stroboscope effect metric (SVM) 0.4 Dimensions & Weight Overall length 110.00 mm Diameter 35.00 mm Tube diameter 27,0 mm Product weight 42.00 g Temperatures & operating conditions Ambient temperature range -20… 45 °C 1) Maximum temperature at tc test point 72 °C 1) Temperature surrounding the lamp – for enclosed luminaires: temperature inside of the luminaire Lifespan Lifespan L70/B50 at 25 °C 30000 h Additional product data Base (standard designation) G24d-1 Mercury-free Yes Design / version Frosted Capabilities Dimmable No Certificates & Standards Type of protection IP20 Standards CE, EAC, UKCA Photobiological safety group acc. to EN62778 RG0 Country-specific categorizations Order reference DULUX LED D10 E Categories: Bulbs, Light Sources Tags: 10w, 2 pin, 4000k, G24d, led, NATURAL . NEUTRAL, office lighting, pl Brand: LEDVANCE
